Product Summary

The mc1413BDR2G is a seven NPN Darlington connected transistor.

Parametrics

MC1413BDR2G absolute maximum ratings: (1)Output Voltage, VO: 50 V; (2)Input Voltage, VI: 30 V; (3)Collector Current — Continuous, IC: 500 mA; (4)MC1413BDR2G Base Current — Continuous, IB: 25 mA; (5)Operating Ambient Temperature Range, TA: -40 to +85℃; (6)Storage Temperature Range, Tstg: -55 to +150℃; (7)MC1413BDR2G Junction Temperature, TJ: 150℃.

Features

MC1413BDR2G features: (1)well suited for driving lamps, relays, or printer hammers in a variety of industrial and consumer applications; (2)MC1413BDR2G high breakdown voltage and internal suppression diodes; (3)freedom from problems associated with inductive loads; (4)MC1413BDR2G Peak inrush currents to 500 mA; (5)can drive incandescent lamps.

Diagrams

mc1413BDR2G schematic diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MC1413BDR2G
MC1413BDR2G

ON Semiconductor

Transistors Darlington High Voltage High Current Darlington

Data Sheet

0-1: $0.35
1-25: $0.29
25-100: $0.21
100-500: $0.17
