Product Summary

The 10SVP56M is a standard SMD type product. It can support lead free-reflow. The applications of 10SVP56M include surface mounted type switching power supplies.

Parametrics

10SVP56M specifications: (1)Rated voltage: 10V; (2)Rated capacitance: 56μF; (3)ESR 100kHz to 300kHz(max.): 45 mΩ; (4)Rated ripple current: 1700mArms; (5)Tangent of loss angle(max.): 0.12; (6)Leakage current(max.): 112μA.

Features

10SVP56M features: (1)Capacitance: 56μF; (2)Capacitance Tolerance: ±20%; (3)Voltage Rating: 10V; (4)ESR: 0.045ohm; (5)Life Time @ Temperature: 2000 hours @ 105°C; (6)Height: 5.9mm; (7)Diameter: 6.3mm; (8)Operating Temperature Range: -55°C to +105°C; (9)AC Ripple Current: 1700mA; (10)Capacitor Mounting: SMD; (11)External Depth: 6.6mm; (12)External Length /Height: 5.9mm; (13)External Width: 6.6mm; (14)Package /Case: C6; (15)Series: SVP; (16)Termination Type: SMD; (17)Tolerance: ±20%; (18)Voltage Rating V DC: 10V.

Diagrams

10SVP56M dimensions
