Product Summary

The HCPL-063L-500E is an optically coupled gate that combines a GaAsP light emitting diode and an integrated high gain photo detector. An enable input allows the detector to be strobed. The output of the HCPL-063L-500E is an open collector Schottky-clamped transistor. The internal shield provides a guaranteed common mode transient immunity specifi cation of 15 kV/μs at 3.3V. The applications of the HCPL-063L-500E include Isolated line receiver, Computer-peripheral interfaces, Microprocessor system interfaces, Digital isolation for A/D, D/A conversion, Switching power supply, Instrument input/output isolation, Ground loop elimination, Pulse transformer replacement and Field buses.

Parametrics

HCPL-063L-500E absolute maximum ratings: (1)Storage Temperature, TS: -55 to 125℃; (2)Operating Temperature, TA: -40 to 85℃; (3)Average Forward Input Current, IF: 20 mA max; (4)Reverse Input Voltage, VR: 5 V max; (5)Input Power Dissipation, PI: 40 mW max; (6)Supply Voltage (1 Minute Maximum), VCC: 7 V; (7)Enable Input Voltage, VE: VCC + 0.5V max; (8)Enable Input Current, IE: 5 mA; (9)Output Collector Current, IO: 50 mA max; (10)Output Collector Voltage, VO: 7 V max; (11)Output Collector Power Dissipation, PO: 85 mW max; (12)Lead Solder Temperature, TLS: 260℃ for 10 sec., 1.6 mm below seating plane.

Features

HCPL-063L-500E features: (1)3.3V/5V Dual Supply Voltages; (2)Low power consumption; (3)15 kV/s minimum Common Mode Rejection (CMR) at VCM = 1000 V; (4)High speed: 15 MBd typical; (5)LVTTL/LVCMOS compatible; (6)Low input current capability: 5 mA; (7)Guaranteed AC and DC performance over temperature:- 40℃ to +85℃; (8)Available in 8-pin DIP, SOIC-8; (9)Strobable output (single channel products only); (10)Safety approvals: UL, CSA, IEC/EN/DIN EN 60747-5-2.

Diagrams

HCPL-063L-500E function diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
HCPL-063L-500E
HCPL-063L-500E

Avago Technologies

High Speed Optocouplers 15MBd 2Ch 5mA

Data Sheet

0-1: $3.34
1-25: $2.73
25-100: $2.42
100-250: $2.18
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
HCPL-0201
HCPL-0201

Avago Technologies

High Speed Optocouplers 5MBd 1Ch 1.6mA

Data Sheet

0-1: $1.95
1-25: $1.60
25-100: $1.42
100-250: $1.27
HCPL-0201#060
HCPL-0201#060

Avago Technologies

High Speed Optocouplers 5MBd 1Ch 1.6mA

Data Sheet

0-280: $1.30
280-500: $1.22
500-1000: $1.15
1000-2000: $1.08
HCPL-0201#500
HCPL-0201#500

Avago Technologies

High Speed Optocouplers 5MBd 1Ch 1.6mA

Data Sheet

0-885: $1.22
885-1500: $1.15
1500-3000: $1.08
3000-6000: $1.01
HCPL-0201#560
HCPL-0201#560

Avago Technologies

High Speed Optocouplers 5MBd 1Ch 1.6mA

Data Sheet

0-885: $1.24
885-1500: $1.17
1500-3000: $1.10
3000-6000: $1.03
HCPL-0201-000E
HCPL-0201-000E

Avago Technologies

High Speed Optocouplers 5MBd 1Ch 1.6mA

Data Sheet

0-1: $1.95
1-25: $1.60
25-100: $1.42
100-250: $1.27
HCPL-0201-060E
HCPL-0201-060E

Avago Technologies

High Speed Optocouplers 5MBd 1Ch 1.6mA

Data Sheet

0-280: $1.30
280-500: $1.22
500-1000: $1.15
1000-2000: $1.08
