Product Summary

The HCPL-4504-500E High CMR, High Speed Optocoupler contains a GaAsP LED. The LED is optically coupled to an integrated high gain photo detector. The HCPL-4504-500E has short propagation delays and high CTR. It also has a guaranteed propagation delay difference (tPLH-tPHL). These features make the HCPL-4504-500E an excellent solution to IPM inverter dead time and other switching problems. The applications of the HCPL-4504-500E include Line receivers, Short propagation delays and low input-output capacitance, High speed logic ground isolation, TTL/TTL, TTL/CMOS, TTL/LSTTL, Replaces pulse transformers, Save board space and weight.

Parametrics

HCPL-4504-500E absolute maximum ratings: (1)Storage Temperature: -55 to 125 ℃; (2)Operating Temperature: -55 to 100 ℃; (3)Average Forward Input Current: 25 mA; (4)Peak Forward Input Current (50% duty cycle, 1 ms pulse width): 50 mA; (5)Peak Transient Input Current (≤1 μs pulse width, 300 pps): 1 A; (6)Reverse LED Input Voltage (Pin 3-2): 5 V; (7)Input Power Dissipation: 45 mW; (8)Average Output Current (Pin 6): 8 mA; (9)Peak Output Current: 16 mA; (10)Supply Voltage (Pin 8-5): -0.5 to 30 V; (11)Output Voltage (Pin 6-5): -0.5 to 20 V; (12)Output Power Dissipation: 100 mW; (13)Lead Solder Temperature (Through-Hole Parts Only) 1.6 mm below seating plane, 10 seconds: 260 ℃.

Features

HCPL-4504-500E features: (1)Short propagation delays for TTL and IPM applications; (2)15 kV/μs minimum Common Mode Transient immunity; (3)at V CM = 1500 V for TTL/load drive; (4)High CTR at TA = 25℃: >25% for HCPL-4504/0454, >23% for HCNW4504, >19% for HCPL-J454; (5)Electrical specifications for common IPM applications; (6)TTL compatible; (7)Open collector output; (8)Safety approval: UL recognized: 3750 V rms/1min. for HCPL-4504/0454/J454, 5000 V rms/1min. for HCPL-4504 Option 020 and HCNW4504.

Diagrams

HCPL-4504-500E circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
HCPL-4504-500E
HCPL-4504-500E

Avago Technologies

High Speed Optocouplers 1MBd 1Ch 12mA

Data Sheet

0-590: $0.88
590-1000: $0.83
1000-2000: $0.77
2000-5000: $0.72
