SS-5GL

Subminiature snap action switch, 5A, 500VDC, SS-5GL

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~1.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~1.50

PartNumber:: SS-5GL

Brand:: OMRON Corporation - Omron | Pack: DIP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. fiona's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-29

From Other Seller

Part Number:SS-5GL
US $0.50 - 1.50
YL-G709

US $65.00 - 68.00 / Piece
(0) Remove
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SS-5GL is a subminiature snap action switch.

Parametrics

SS-5GL specifications: (1)Mounting Screw Mount; (2)Maximum Movement Differential: 0.8mm; (3)Minimum Over-Travel: 1.2mm; (4)Product Depth: 6.4mm; (5)Maximum AC Voltage Rating: 250V; (6)Product Type Switch Snap Action; (7)Product Height: 25.7mm; (8)Actuator Style Hinge Roller Lever; (9)Maximum DC Voltage Rating: 14V; (10)Maximum Current Rating :5A, 125VAC 14VDC ; (11)Operating Force: 0.49N; (12)Release Force: 0.06N.

Features

SS-5GL features: (1)Economical, subminiature snap action switch offers long service life(30 million operations minimum); (2)All models are free from overtravel restrictions, permit easy setting; (3)Wide switching capacity range from microvoltage/current loads(1mA at 5VDC to high-capacity loads 10.1A at 250VAC); (4)Standard operating force, low force or super-low force models available; (5)RoHS compliant.
